Description
INTERFACE FUTURE
ADSL2+ Interface
● Supports ITU G. 992.1 (G. drnt), G. 992.3 ADSL2 (G.dmt.bis), and
G.992.5 ADSL2+ Annex A (G.dmt. bitplus)
● Supports ANSI T1.413 Issue 2
● Supports Annex L (RE
ADSL)
● Supports the configuration of eight VPINCls
● Supports manual configuration of VPINCI parameters
USB Interface
● Supports USB 2.0 host Interface
● Supports Huawei HSPA USB interface link driver
● Supports mutual data
backup of ADSL2+ uplink and USB interface uplink
● Supports USB mass storage device Supports USB printer
Ethernet Interfaces
● Provides four 10/100 M auto-sensing Ethernet interfaces
● Supports Ethernet switch function Supports 802.3u
● Supports testing Ethernet with the diagnosis button
WiFi Interface
● Supports 802.11 b, 802.11 g and 802.11 n
● Supports 32 connections
● Supports SSID hiding
● Supports channels selection
● Supports Open System/Shared Key authorization
● Support WPS
● Supports WEPITKIP/AES Supports WPA-PSKlWPA2-PSK
● Support WMM
POTS Interfaces
● Supports two POTS telephones
● Supports FXO line emergency function
FUNCTIONS
HSPA Link Backup
● Supports the wireless backup of data
● Supports the wireless backup of voice
● Supports enable and disable the wireless voice function
● Supports the Personal Identification Number (PIN) code
● Supports TR-069 extensible configuration
● Supports enable and disable the wireless backup function
● Supports
automatic switching between the DSL link and HSPA link
Route
● Supports the static route
● Supports RIP V1 &V2
● Supports port forwarding
● Supports IGMP Proxy/IGMP snooping
NAT
● Supports NAT and NAPT
● Supports DMZ
● Supports port mapping
● Supports port triggering
QoS
● Supports Flexible QoS
● Supports the traffic classification based on the interfaces,
source MAC
addresses, destination MAC addresses,
network protocol, VLAN ID,
802.1 D priority,
source IP addresses, destination IP addresses, DSCp,
source port, and destination port
● Supports WLAN Qos
SIP VoIP
● Supports SIP (RFC 3261)
● Supports SDP ,
● Supports RTP (RFC 1889) and RTCP (RFC 1890)
● Supports G.711a and G.711 u
● Supports the value-added services, such as call transfer, call waiting, call
hold, and three-way calling Supports 1.38 and G.711 fax
● Supports echo cancellation, silence suppression, and comfort noise generation
(CNG)
● Supports jitter buffer
Security
● Supports 64/128-digit WEP encryption over the WiFi interface
● Supports HEX and ASCII key input over the WiFi interface
● Supports IP/MAC filtering
● Supports parent control
● Supports several levels of firewall configuration Prevents port scanning and
illegal packet attack
Prevents DoS, LAND, SYN Flooding, Ping of Death, ICMP Redirection, Smurf,
Winnuke, Ping Sweep, Teardrop, IP Spoofing, and ARP Attack
● Supports VPN (PPTP, L2Tp, and IPSec) transparent transmission
● Supports the termination of IPsec on the gateway
Network Management
● Supports TR-069, TR-098, TR-1 04, TR-1 06 and TR-111 part 1
● Supports HTIP and HTIPs
● Supports remote/local Web configuration and management
● Supports the remote management and upgrade
● Supports CD configuration
● Supports SNTP
● Supports UPnP
● Supports DHCP Server/Client Supports DNS Server / Client / Reply
Network Protocols
● Supports Annex A ANSI T1.413 Issue 2, ITU-T G.992.1 (G.DMT), G.992.3 (ADSL2) and
G.992.5 (ADSL2+)
● Supports IEEE802.3, IEEE802.3u
● Supports SIp, RFC 3261, SDp, RFC 2327, RTp, RFC 1889, RTCp, RFC 1890
● Supports HTIp, HTIPs
● Supports ITU-T G.994.1
● Supports ITU-T G.997.1 rev 3
● Supports RFC1483/2684
● Supports IPoE, route encapsulation (built in DHCP client) ATM
● Supports ATM Forum UNI 3.1/4.0
● Supports the QoS function based on ATM
● Supports service types, such as CBR, UBR, rt-VBR, and nrt-VBR
● Supports OAMF4/F5 loop (1.610)
TECHNICAL SPECIFICATIONS
· Power Specifications
· Power adapter input: 90-260 V AC
· Power supply to device: 12 V DC, 2 A
· Standard power consumption: < 17 W
● Supports LPS
Working Environment
· Ambient temperature during working: O"C to 40"C
· Storage temperature: -40"C to 70"C
· Ambient humidity during working: 5% to 95% (non-condensing)
Technical Specifications
· Dimensions (length x width x height): 190 mm x 165 mm x 40 mm
· Weight: < 2 kg
